R911318785 (CDB01.1C-SE-ENS-EN2-EN2-NNN-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN2-EN2-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911318785 (CDB01.1C-SE-ENS-EN2-EN2-NNN-L1-S-NN-FW) is a double-axis control section engineered for integration into Rexroth Indramat drive systems, supporting applications such as printing, packaging, and food processing machinery. It operates with a 24 V DC supply, 9 W power consumption, and a 6 A inrush current. The unit provides two analog outputs and one RS232 serial interface input, with independent connection to the power section. Supported communication includes SERCOS Interface, with options for EnDat 2.1 and IndraDyn/hiperface encoders. Control function cycle times are configurable: velocity (250–500 μs), current (125–1000 μs), and position (500–1000 μs). The device is equipped with 22 digital inputs, 4 digital outputs, and L1 safety technology. Physical dimensions are 49.5 mm (D) × 103 mm (W) × 322.6 mm (H).

Technical Specifications

Power Supply
24-volt DC

Power Consumption
9 W

Inrush Current
6 Amp

Number of Analog Outputs
2

RS232 Serial Interface Input
1

Cycle Time Velocity
250 - 500 microseconds

Cycle Time Current
125 - 1000 microseconds

Cycle Time Position
500 - 1000 microseconds

Safety Technology
L1 (starting lockout)

Encoders Option 2 and 3
EnDat2.1 encoders

Option 1 Encoder
IndraDyn hiperface encoder

Number of Digital Inputs
22

Number of Digital Outputs
4

Max Pulse width
60 milliseconds

Min SERCOS cycle duration
1000 microseconds
