R911320290 (CDB01.1C-SE-ENS-EN2-NNN-EN1-S1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN2-NNN-EN1-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911320290 (CDB01.1C-SE-ENS-EN2-NNN-EN1-S1-S-NN-FW) is a Bosch Rexroth CDB01 control section that integrates with power sections to execute specialized machine automation functions. It features two digital inputs configurable as analog voltage inputs, two analog outputs, and provides a current control cycle of 125 microseconds. The unit supports SERCOS master communication and includes interfaces for 12V and 5V encoder systems, including sin-cos encoders, 5V TTL square wave encoders, and a 15-pole resolver/HSF encoder interface. It accommodates Indradyn, Hiperface, 1 Vpp, TLL, and EnDat 2.1 encoder protocols, and is compliant with IEC 61800-3 category C3. The hardware employs PELV (Protective Extra-Low Voltage) systems for electrical protection. Firmware is not included.

Technical Specifications

Product Family
CDB01 Control Unit

Product Type
BASIC UNIVERSAL

Digital Inputs
2

Analog Outputs
2

Current Control Cycle
125 μs

Encoder systems supply voltage
12V

Evaluation Encoder Interface supply voltage
5V

Interface
Resolver and HSF encoder interface with 15 poles

Safety Connection
Protective Extra-Low Voltage (PELV) systems

Classification
Product of category C3 per IEC 61800-3

Applicable Area
Industrial areas

Firmware
Can be used but ordered separately

Shipping
Global
