R911328505 (CDB01.1C-SE-ENS-ENS-NNN-MEM-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-NNN-MEM-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911328505 (CDB01.1C-SE-ENS-ENS-NNN-MEM-S2-S-NN-FW) is a universal control section designed according to IEC 61131, Type 1 specifications. It is equipped with a 24VDC power supply, consuming 9W, and integrates digital inputs and outputs that are not suitable for low resistance source operation. The unit incorporates two configurable Type 2 and Type 3 inputs, suitable for use as probes to prevent erroneous signal evaluations when connected to bounce-free components. It features a circular RS-232 interface for programming, parameterization, and diagnostic functions. The control section supports a memory card with preloaded firmware and parameter transmission, and includes an optional MEM module for incremental encoder and absolute value signal emulation with overload protection. Communication is facilitated via the SERCOS interface; encoder options include Indradyn, Hiperface, 1 Vpp, and TTL. The device operates with a current control cycle time of 125μs and supports three selectable switch frequencies.

Technical Specifications

Digital Inputs and Outputs Standard
IEC 61131, Type 1

Probe Inputs
2 each of Type 2 and Type 3

Minimum Pulse Width
4μs

Output Type
High-side switches

Switching Frequencies
2kHz, 4kHz and 8kHz

Interface
8-pole circular RS 232 serial

Power Consumption
9W at 24VDC

Overload Protection
Yes

Digital Input Type
Probe-type for less sophisticated measuring marks

Axes
Two

Current Control Cycle Time
125µs

Delivery
Through worldwide logistics team
