R911329072 (CDB01.1C-PB-ENS-ENS-EN2-MA1-S2-S-NN-FW)

CDB Control Units

CDB01.1C-PB-ENS-ENS-EN2-MA1-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329072 (CDB01.1C-PB-ENS-ENS-EN2-MA1-S2-S-NN-FW) is a drive controller module that features a single-line display for essential operating data such as target value, input current, and voltage. User inputs and navigation are managed through integrated keys, facilitating manual operation and configuration. This unit incorporates a CDB01.1 control section with safety technology, supports PROFIBUS master communication, and offers compatibility with encoder interfaces including IndraDyn, Hiperface, 1Vpp, TTL, and EnDat 2.1 via the X4.1 and X4.2 connections. Suitable connection wire sizes range from 0.25 to 0.5 mm². Cooling requirements should be adhered to as outlined in the technical documentation. The controller also integrates IEC-compliant motion logic, and the control panel interface connects at H1.

Technical Specifications

Display
Single Line

Control Mechanism
Keys

Encoder Interfaces
TTL, 1Vpp, and EnDat 2.1

Optimal Wire Type
Stranded wire with a square of 0.25 - 0.5 mm

Cooling Requirements
Read from provided manual

Firmware Features
IEC-compliant motion logic

Serial Interface Connection Point
X2

Protection Mechanism
Protection Diode

Control Panel Connection Point
H1

Maximum Ambient Temperature
Not Specified

Maximum Humidity
90%

Physical Size
Modest

Available at
Indramat USA

Safety Technology
Standardized

Shipping
Global

Integrated Motion Logic
Standardized.
