R911329311 (CDB01.1C-SE-EN2-EN2-EN1-EN1-S2-S-NN-FW)

CDB Control Units

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 22 Seconds

The Bosch MPN R911329311 (CDB01.1C-SE-EN2-EN2-EN1-EN1-S2-S-NN-FW) is a double-axis modular control section designed for use with IndraDrive drive controllers. It requires a standard control panel for configuration and operation, which must be attached prior to system startup. This module is equipped with five fully populated slots for optional hardware modules, including four encoder modules—two supporting HSF/RSF encoders and two for EnDat 2.1/1Vpp/TLL encoders—and one safety module supporting safe stop 2 and safe braking functionality. The device features a SERCOS interface for real-time master communication. Firmware is not included with the R911329311 and must be acquired separately.

Technical Specifications

Type
Modular Control Section

Compatible With
Standard Control Panel

Slot Availability
5 slots for optional hardware module

Regime
Four encoder modules and one safety module

Encoder Modules
2 HSF / RSF modules and 2 EnDat 2.1 modules

EnDat 2.1 Module Compatibility
Encoders operating at 5 Volt supply voltage

Firmware
Ordered separately

Global Shipping
Yes.
