R911329435 (CDB01.1C-SE-ENS-EN2-EN2-EN2-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN2-EN2-EN2-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911329435 (CDB01.1C-SE-ENS-EN2-EN2-EN2-S2-S-NN-FW) is a double-axis drive controller designed for industrial automation applications. It features a CDB01.1 control section and master communication via the SERCOS interface. The unit provides 18 to 22 digital inputs, an RS232 serial interface, and supports encoder feedback options including Indradyn, Hiperface, 1 Vpp, TLL, and EnDat 2.1. The controller enables adjustable velocity, current, and position control with configurable cycle times from 250 to 1000 microseconds, with a minimum SERCOS cycle time of 1000 microseconds depending on firmware. It includes an integrated S2 safety option. The device has physical dimensions of 49.5 mm depth, 103 mm width, and 322.5 mm height, and operates on a 24V input via 0.75 to 1.50 mm twisted wire. Applications include machine tools, packaging, and food processing automation.

Technical Specifications

Product Type
Industrial Automation Equipment

Usage
Industrial Setting

Digital Inputs
18 to 22

Serial Interface Port
1 RS232

Velocity Control
250 to 500 microseconds

Current Control
125 microseconds

Position Control
500 to 1000 microseconds

Functionality
Dual-axis Drive Controller

SERCOS Cycle Time
1000 milliseconds Minimum

Encoder Option 4
EnDat2.1

Safety Option
S2 (safe motion)

Option 1 Encoder
IndraDyn Hiperface

Option 2 Encoder
EnDat2.1

Control Panel
Standard

Voltage Input
24V

Wire Diameter
0.75 to 1.50mm.
