R911329743 (CDB01.1C-SE-ENS-EN1-NNN-NNN-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN1-NNN-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911329743 (CDB01.1C-SE-ENS-EN1-NNN-NNN-S2-S-NN-FW) functions as a control section for drive systems, equipped with four digital outputs, two analog outputs, one analog input, one relay contact, and an RS232 serial interface. It supports encoder types such as IndraDyn, Hiperface, 1 Vpp, and TTL (option 1) and includes SERCOS interface for master communication. Supported wiring ranges from 0.75 to 1.50 mm stranded conductors. The module offers velocity, current, and position control, operates on a 24-watt DC supply, incorporates the S2 safety option, and requires firmware to be obtained separately.

Technical Specifications

Digital Outputs
4

Relay Contact
1

Analog Input
1

Wire Diameter
0.75 to 1.50 mm

Control Panel
Standard

Digital Inputs
18 to 22

Velocity Control Cycle Time
250-500 microseconds

Current Control Cycle Time
125-500 microseconds

Position Control Cycle Time
250-500 microseconds

Analog Outputs
2

Serial Interface Port
RS232

Option 1 Encoder
indraDyn/hiperface

Communication Interface
SERCOS interface master

Option 2 Encoder
HSF/RSF

Power Supply
24-watt DC

Power Usage
9 watts

Safety Option
S2

Minimum SERCOS Cycle Period
1000 milliseconds

Maximum Pulse Width
60 milliseconds

Firmware
Sold Separately

Availability
In Stock at Indramat USA

Global Shipping
Available
