R911329990 (CDB01.1C-PB-EN2-EN2-NNN-NNN-S2-S-NN-FW)

CDB Control Units

CDB01.1C-PB-EN2-EN2-NNN-NNN-S2-S-NN-FW Series Image

In Stock, Shipping Varies

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 21 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911329990 (CDB01.1C-PB-EN2-EN2-NNN-NNN-S2-S-NN-FW) is a single-axis drive control unit measuring 241 mm x 103 mm x 49.5 mm, designed for precise motor control applications. It features a single line display for operational data including target value, input current, and voltage. The unit requires operation in controlled environmental conditions for temperature, humidity, and altitude. Master communication is provided via PROFIBUS. The module is equipped with dual encoder interfaces supporting EnDat 2.1, 1Vpp, and TLL signal formats. Connection is established via 0.25–0.5 mm² stranded wire, as specified in the CSH manual, with designated control panel and serial interface terminals. Over-current and over-voltage protection using a protective diode is advised. Proper configuration and adherence to installation and cooling guidelines are necessary for safe operation.

Technical Specifications

Display
Single line

Control Section Dimensions
241mm x 103mm x 49.5mm

Unit Type
Drive Control Unit

Functionality
Single-axis

Configuration
Required before operation

Security Features
Included

Connection point for Control panel interface
H1

Recommended Wire for Maximum Efficiency
Stranded 0.25 - 0.5 mm(square)

Dedicated Serial Interface
X2

Protection
Required against over-current and over-voltages

Usage
By a well-trained operator only

Additional Protection Option
Control Cabinet

Shipping
Global from Indramat USA

Product Inspection
Conducted before shipping

Product Packing
High attention to detail

Customer Support
Provided by Indramat USA.
