R911329991 (CDB01.1C-PB-ENS-EN2-NNN-NNN-S2-S-NN-FW)

CDB Control Units

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 18 Seconds

The R911329991 (CDB01.1C-PB-ENS-EN2-NNN-NNN-S2-S-NN-FW) is a Bosch Rexroth dual-axis control unit from the CDB01.1C series, designed for automated multi-axis applications in restricted spaces. It features an integrated standard operator panel and stores parameters on an MMC card. The unit operates with a maximum power consumption of 9 W and an inrush current of 6 A. Supported master communication protocol is PROFIBUS. Encoder interface options include Indradyn/Hiperface/1 Vpp/TLL and EnDat 2.1/1Vpp/TLL. Safe Motion technology is implemented, and firmware is supplied separately.

Technical Specifications

Functionality
Two digital axis

Operator panel type
Standard

Parameters Storage Device
MMC

Power Consumption
9 Watts

Inrush Current
6 Amperes

Safety Features
Built-in

Encoder Interface Option 1
IndraDyn motors

Encoder Interface Option 2
EnDat 2.1, 1 Vpp, 5 V TTL

Safety Technology
Safe Motion.
