R911329992 (CDB01.1C-PB-ENS-ENS-EN2-EN2-L2-S-NN-FW)

CDB Control Units

CDB01.1C-PB-ENS-ENS-EN2-EN2-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329992 (CDB01.1C-PB-ENS-ENS-EN2-EN2-L2-S-NN-FW) is a Rexroth CDB01 series double-axis control section for IndraDrive systems, enabling control and monitoring of two electric motor axes when installed in a compatible drive controller. Communication is achieved via a PROFIBUS master interface. It features two pairs of encoder interfaces: two standard options supporting Indradyn, Hiperface, 1 Vpp, and TTL signals, and two supporting EnDat 2.1, 1 Vpp, and TTL encoders. Encoder supply is provided at 12 V and 8 V DC. The control section supports storage of firmware and drive parameters via an optional MultiMediaCard, integrates a control panel for basic operations, and includes Safe Torque Off (STO) safety functionality at category 3 PL e/SIL 3.

Technical Specifications

Product type
double-axis control sections

Communication module
PROFIBUS

Number of standard encoder interfaces
2

Supply voltage for the standard encoder
12 Volts

Number of Resolver and HSF encoder interfaces
2

Supply voltage for Resolver and HSF encoder interfaces
8 Volts DC or 18.2 Volts AC

Device type
Compact

Mounting
plug-in

Maximum number of times to mount or dismount
20

Firmaware, operating data, axis-oriented drive parameters storage
Optional MultiMediaCard (MMC)

Control panel
Standard

Safety technology option
Safe Torque Off (STO)

Safety Category
3 PL e/SIL 3

Global shipment
Yes
