The R911329994 (CDB01.1C-PB-ENS-ENS-NNN-MA1-S2-S-NN-FW) is a Bosch Rexroth CDB series dual-axis control section designed for integration with drive controllers. It features a PROFIBUS communication module using a 9-pin female D-Sub connector at X30, supporting a signal voltage of 5V ±10% and a power consumption of 2W. The unit includes multiple digital I/O conforming to IEC 61131 Type 1, a memory card slot for extended functionality, an H1 interface for control panel connections (without hot plug capability), a connectable terminating resistor for proper bus configuration, one relay contact (normally open), two digital/analog voltage inputs, and an RS232 serial interface for programming and diagnostics. Encoder support is provided via two Indradyn/Hiperface/1 Vpp/TLL channels; a third encoder option is not equipped.

Technical Specifications

Product Type
Control Section

Product Group
CDB

Number of Axes
2

Communication Module
PROFIBUS

Signal Voltage
5V +/*-10%

Maximum Repeater Supply Current
75mA

Control Panel Interface
H1

Digital Inputs and Outputs
Compliant with IEC 61131, Type 1

Normally Open Relay Contact
1

Number of Digital Inputs Functioning as Analog Voltage Input
2

Serial Interface
RS 232

Power Consumption of PROFIBUS Module
2W
