R911329999 (CDB01.1C-SE-ENS-EN2-EN2-NNN-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN2-EN2-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329999 (CDB01.1C-SE-ENS-EN2-EN2-NNN-S2-S-NN-FW) is a Bosch Rexroth control section featuring 22 digital inputs and four digital outputs, a single analog input, and a standard control panel. It supports either EnDat 2.1 or IndraDyn Hiperface encoder options for flexible feedback integration. The control current cycle is 125 microseconds, with speed and position control ranges between 250 and 1000 microseconds. A SERCOS interface module enables master communication with a 1000-microsecond cycle period. The device operates at a pulse width of 60 milliseconds and a selectable PWM frequency between 2 and 8 kHz, with a total power consumption of 9 W. The unit incorporates an S2 safety option. Comprehensive installation and operation instructions must be followed when deploying this module.

Technical Specifications

Product Type
Control sections

Firmware Capabilities
Available but Purchased separately

Digital Inputs
22

Control Current
125 microsecond

Speed Control Range
250-500 microsecond

Position Control Range
500-1000 microsecond

Power Usage
9 watts

Analog Input
1

Digital Outputs
4

Control Panel
Standard

SERCOS Cycle Period
1000 microseconds

Analog Output
2

Pulse Width
60 milliseconds

PWM Frequency
2 kHz to 8 kHz in multiples of 2kHz increments

Communication Module
SERCOS interface master

Safety Feature
S2 (safe motion) option
