The Bosch Rexroth MPN R911330002 (CDB01.1C-SE-ENS-EN2-NNN-NNN-L2-S-NN-FW) is a configurable dual-axis control section supporting IEC 61131 standard digital I/O with input voltage from -3V to 30V. It features a minimum cycle time of 1000 μs for SERCOS master communication, and supports encoder options including Indradyn, Hiperface, 1 Vpp, TLL, and EnDat 2.1 interfaces. The unit provides four combined I/Os, a Normally Open relay contact designed for up to 20 disconnections from the power section, and Safe Torque OFF accessible via a 9-pin D-Sub connector (X41). Separate power supplies are required for isolated I/O, and direct connection is made using matching cross-section wires or TWIN ferrules.

Technical Specifications

Configuration
Two axes

Integrated Features
Digital inputs and outputs according to IEC 61131

Digital Input Voltage
Between -3V and 30V

Minimum SERCOS Cycle Time
1000µs

Current, Position and Velocity Control Cycles
Two

Relay Contact
One Normally Open

Inrush Current
6A

Required Wire Type
Stranded wires

Combined I/Os
Four

Plug-in Removal Limit
20 times

Backup Support
One yea
