R911330006 (CDB01.1C-SE-ENS-ENS-NNN-MA1-L2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-NNN-MA1-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330006 (CDB01.1C-SE-ENS-ENS-NNN-MA1-L2-S-NN-FW) is a Bosch Rexroth IndraDrive CDB01.1C-SE control section designed for dual-axis applications within the basic range. It features circuit board interfaces and supports optional modules, with parameters for both axes storable on an optional MMC. The unit provides SERCOS master communication and is equipped with two encoder interfaces supporting IndraDyn, Hiperface, 1 Vpp, and TLL protocols; a third encoder option is not equipped. Certified safety features include Safe Torque Off (STO) in accordance with EN 138491-1 and EN 62061. Additional specifications include an analog I/O extension on the fourth interface, a standard operator panel for local control, IP20 protection class, and operational temperature range of 0 to 40°C (extendable to 55°C with power reduction). The module tolerates transport and storage temperatures between -25°C and 70°C, supports mains frequencies of 50–60 Hz (+/-2%), and operates with a 3-phase AC input voltage of 400–480 V.

Technical Specifications

Product Category
IndraDrive

Product Type
Control Section

Range
Basic

Circuit Board Interfaces
Yes

Optional Modules
Yes

Control Type
Universal Double-Axis

Storage
Optional MMC

Safety Technology
EN 138491-1 / EN 62061, Safe Torque Off

Control Communication
SERCOS II

Encoder Interfaces
2 Compatible with IndraDyn Motors

Third Interface
Not equipped

Fourth Interface
Analog Input/output extension

Operator Panel
Standard

Moisture Protection
No condensation/icing

Transportation Temperature
-25 to 70 degrees C

Storage Temperature
-25 to 55 degrees C

Protection Degree
IP 20

Mains Frequency
50 to 60 Hz±2

Mains Input Voltage
3 x AC 400 to 480

Shipping
Global
