R911331013 (CDB01.1C-SE-EN1-EN1-NNN-NNN-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-NNN-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911331013 (CDB01.1C-SE-EN1-EN1-NNN-NNN-S2-S-NN-FW) is an industrial control unit designed for the regulation of servo and synchronous motors within automation systems when used with compatible power supply modules. It features an IP20 enclosure, providing basic protection against solid objects larger than 12 mm; enhanced protection is achieved by installation within a control cabinet rated at least IP54. This model supports SERCOS interface for master communication and is configured for encoder options HSF/RSF in both Option 1 and Option 2, with Option 3 not equipped. The unit integrates a standard control console with a single-line display and status LEDs for operational feedback and monitoring. Configuration data is stored internally on a memory card. The acceptable operating temperature range is 0 to 40°C. Installation and setup should be performed by qualified personnel according to the device documentation.

Technical Specifications

Application
Industrial and Synchronous Motors

Protection class
IP20

Installation
Integrated into IP54 Protective Cabinet

Control Panel
Standard with Display and LEDs

Inbuilt Memory
Yes

Operating Temperature
0 to 40 degrees Celsius

Global Shipping
Available

Product Type
Industrial Drive Controller

Servo System Compatible
Yes
