R911331253 (CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911331253 (CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW) is a control section from the Bosch Rexroth CDB01 series designed for precision motion control within the IndraDrive system. It utilizes SERCOS III communication, conforms to IEEE 802.3 standards, and is equipped with dual encoder interfaces (IndraDyn, Hiperface, 1 Vpp, TLL, HSF/RSF) supporting a 12V supply, enabling compatibility with IndraDyn S MSK motor encoder systems and similar devices. The module features a single-line display for operating status, diagnostic error, and warning indications. Control elements on the unit allow adjustments to transmission power and rate, position referencing, and error memory review. Electrical connections are made via spring terminals and screw terminal blocks. The typical inrush current is 6A with a maximum pulse width of 60ms. Firmware is required and supplied separately.

Technical Specifications

Version
1

Control Communication Module
SERCOS III

Suitable Applications
High-precision motion control

Interface
Standard IEE 802.3

Encoder Interfaces
Two standard

Control Panel
Standard model

Typical Inrush Current
6A

Maximum Pulse Width
60ms

Connection Type
Spring terminals and screw terminal blocks

Firmware Support
Yes

Availability
Global
