R911331722 (CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911331722 (CDB01.1C-SE-ENS-ENS-EN1-EN1-NN-S-NN-FW) is a control section from Bosch Rexroth featuring non-linear input resistance, high-side switches, and a maximum mounting cycle count of 20. This unit supports SERCOS interface for master communication, digital outputs, and an integrated distortion LED for SERCOS status indication. RS 232 serial communication is provided at the X2 terminal. The component's terminal blocks accommodate ferrule-secured wire ends with crimping tools, and it is powered through 0V and 24V connectors, operating at 9 W with 24 VDC and tolerating an initial current of up to 6 A. The analog input requires dual-shielded cabling. Supported encoder options include Indradyn, Hiperface, 1 Vpp, TLL, HSF, and RSF variants. Three switching frequencies are available, and the SERCOS interface is also used for diagnostics and programming.

Technical Specifications

Safety Option
None

Probe Input Resistance
Non-linear

Mounting/Dismounting
Limited to 20 times

Digital Outputs
High-side switches

SERCOS Interface Distortion LED
Integrated

Connectivity
RS 232 serial interface at the X2 connecting point

Inrush Current
6A

Analog Input Connection
Cable with shield at either end

Power Consumption
9W at 24VDC

Digital Output Energy Absorption Capacity
Present

Probe Inputs Switching Elements
Bounce-free electronic switches

Switching Frequencies
Three

SERCOS Interface Functionality
Programming, diagnosis, parameterization

Axis
Double.
