R911333455 (CDB01.1C-PB-ENS-EN1-NNN-EN2-S2-S-NN-FW)

CDB Control Units

Rated 4.8 stars (5 total reviews)

CDB01.1C-PB-ENS-EN1-NNN-EN2-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Or speak to a sales representative for additional information:

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911333455 (CDB01.1C-PB-ENS-EN1-NNN-EN2-S2-S-NN-FW) model is a highly reliable and affordable motion control application with a wide power range. Engineered with IEC-compliant motion and advanced firmware features, the model ensures efficient communication via a PROFIBUS specific port and the master communication is assigned to X4.1 connection point. Featuring safety provisions like Safe Motion and encoder emulation at the X8.2 connection, it supports various optical encoder interfaces, including EnDat 2.1, 1Vpp, and TTL. The model has numerous digital inputs and outputs for connecting peripheral devices and it's exclusively designed for controlling devices approved by the manufacturer. It guarantees user-friendliness with a standard control panel offering varied current, velocity, and position control. This compact model is easy to install and store, provided you adhere to the manual instructions. Shipment is globally available and comes with a one-year warranty from Indramat USA. Please note, the firmware is not included in the package.

Technical Specifications

Power Range
Broad

Connection Point for Master Communication
X4.1

Communication Interface
PROFIBUS dedicated port

Motion Control Feature
Encoder emulation at connection X8.2

Included Safety Features
Safe Motion

Supported Optical Encoder Interfaces
EnDat 2.1, 1Vpp, TTL

Additional Features
Multiple digit inputs and outputs

Size
Compact

Control Panel
Standard

Current Control
62.5 - 125

Velocity Control
125 - 250

Position Control
250 - 500

Encoder Evaluation Feature
Standard

Firmware
Not included in package
