R911335700 (CDB01.1C-SE-ENS-ENS-MEM-MA1-S2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-MEM-MA1-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 13 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911335700 (CDB01.1C-SE-ENS-ENS-MEM-MA1-S2-S-NN-FW) is a dual-axis drive controller from the IndraDrive system, designed for scalable functionality and high performance. It features a SERCOS master communication interface and a standard control panel for transmission power settings, error memory management, and device address configuration. The unit is equipped with two encoder interfaces supporting IndraDyn, Hiperface, 1 Vpp, and 5V TTL encoder types, each requiring a 5V supply. It includes a Safe Motion technology module for functions such as safe maximum speed and door locking. The controller is capable of a maximum pulse width of 60 ms and can handle an inrush current of 6 A. Firmware must be ordered separately for device operation.

Technical Specifications

Interface Type
SERCOS

Control Panel
Standard

Encoder interfaces
Standard, Two

Supply Voltage
5V

Firmware
Order Separately

Safety Technology Module
Safe Motion

Safety Rating
SIL2/cat. 3 PL d

Inrush Current
6A

Maximum Pulse Width
60ms

Shipping Availability
Global

Common Misspellings

Warranty

Indramat USA 1 Year Warranty
