R911338995 (CDB01.1C-SE-ENS-EN1-NNN-NNN-L2-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN1-NNN-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911338995 (CDB01.1C-SE-ENS-EN1-NNN-NNN-L2-S-NN-FW) is a CDB01.1 control section for Rexroth Indramat drive systems, designed as a double-axis unit featuring a SERCOS interface master communication protocol. It supports an IndraDyn Hiperface encoder as its primary option and HSF/RSF encoder as a secondary option. The module provides 22 digital inputs, 1 analog input, 2 analog outputs, and 1 relay contact. It supports adjustable cycle times for velocity, current, and positioning control, with a minimum SERCOS cycle time of 1000 microseconds and a maximum pulse width of 60 milliseconds. The device operates on a 24V DC power supply, with a power consumption of 9W and a 6A inrush current. L2 safety technology and standard control panel configuration are integrated. All installation and operation should reference the user manual for compatibility with specified accessories.

Technical Specifications

Product Type
Drive System

Encoder Option 1
IndraDyn

Encoder Option 2
HSF/RSF

Digital Inputs
22

Analog Inputs
1

Maximum Pulse Width
60 milliseconds

Minimum SERCOS cycle time
1000 microseconds

Analog Outputs
2

Relay Contacts
1

Velocity Range
250-500 microseconds

Current Range
125-1000 microseconds

Position Range
500-1000 microseconds

Control Panel
Standard

Communication Interface
SERCOS Master

Safety Technology
L2 - Safe Torque Off

Power Consumption
9 W

Inrush Current
6 Amp

Power Source
24-volt DC

Separate Power Section
Yes

RS232 serial interface input
1
