R911340354 (CDB02.1B-ET-EC-EC-EM-S4-S4-NN-NN-FW)

CDB Control Units

CDB02.1B-ET-EC-EC-EM-S4-S4-NN-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911340354 (CDB02.1B-ET-EC-EC-EM-S4-S4-NN-NN-FW) is a Rexroth Indramat CDB02 series control section designed for integration within the IndraDrive system and compatible with the HMD01 power section series. This unit features 14 digital inputs, including four probes, and supports master communication via MultiEthernet. Notable interfaces include dual multi-encoder ports and an encoder emulator, as well as a PROFIBUS interface. It incorporates functions such as safe motion, safe torque off, and encoder emulation. The control section operates at 24V DC with a power consumption of 23W, a maximum inrush current below 5A, and a maximum pulse width of 1 ms. The firmware is supplied separately. This module supports optional expansion with the HSZ01 safety zone module and HAT02 control module for inductive loads.

Technical Specifications

Rexroth Indramat Control Section
Yes

IndraDrive System Compatibility
Yes

Training Requirement for Mounting and Dismounting
Yes

Mount and Dismount Limit
20 times

Digital Inputs Number
14

Probes Number
4

Ethernet
Multi-Ethernet

Control Panel
Standard

Axis Control
Double-Axis

Scope
Extended

Communication
Multi-Ethernet

Design
Single

Firmware
Ordered Separately

Display
Single-Line

Power Consumption at DC 24 V
23 W

Maximum Inrush Current
<5 A

Maximum Pulse Width
1 Ms

Safe Motion Power Consumption
2.5 W

Multi-Ethernet Communication Power Consumption
2.7 W

EtherNet Interface LEDs
3.
