R911347715 (CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW)

CDB Control Units

CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911347715 (CDB01.1C-PB-EN1-EN1-EN2-EN2-S2-S-NN-FW) is a double axis universal control section from Bosch Rexroth with a line code of 01. It features slots for memory card integration and connector I/O, with external power supply requirement. The unit provides two type-2 and two type-3 digital inputs, each of which can be configured as a probe. Dimensions are 322.6 x 103 x 49.5 mm. The control supports a maximum serial interface transmission rate of 115 kBaud and includes Safe Motion functionality. Master communication is handled via PROFIBUS, and encoder options include HSF/RSF and EnDat 2.1/1Vpp/TTL. The EnDat encoder interface at X2 provides up to 35 mA output current and 35 Ohm load resistance. Connections are made using spring and screw terminal blocks, with wire ends recommended without ferrules.

Technical Specifications

Line Code
01

Axis
2

Memory Card Slot Presence
Yes

External Supply Voltage Requirement
Yes

Digital Inputs Type 2 and 3
2 Each

Probe Inputs Voltage Rating
24V

Probe Inputs Current Rating
3mA

Product Dimensions
322.6 x 103 x 49.5mm

Firmware
Must be procured separately

Isolated Inputs/Outputs at X31 and X32
Present

Max Pulse Width
60ms

Serial Interface
1 Node

Max Transmission Rate
115k Baud

EnDat 2.1 / 1Vpp / TTL Encoder on its X2 connector
Present

Maximum Outout Current Rating
35mA

DC Load Resistance
35 Ohms

Spring Terminals and Screw Terminal Blocks
Present

Recommended Stripped Length for Wire Ends
10mm

Packaging Type
Military-grade

Common Misspellings
