CSB01.1C-PB-ENS-ENS-L2-S-NN-FW

CSB Drive Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CSB01.1C-PB-ENS-ENS-L2-S-NN-FW from the CSB Drive Controllers series is a configurable control section designed for precision motor management with PROFIBUS Master Communication. This unit features a line code of 01 and supports dual Encoder Option 1: IndraDyn/Hiperface/1Vpp/TTL and Encoder Option 2: IndraDyn/Hiperface/1 Vpp/TTL for versatile feedback integration. Housed in a compact 241 x 103 x 49.5 mm enclosure, the controller plugs directly into the power section to manage a single axis with seamless compatibility. The section's modular architecture accommodates two optional encoder modules and a dedicated safety technology slot for advanced functional safety.



The CSB01.1C-PB-ENS-ENS-L2-S-NN-FW employs a 9-pin D-Sub female connector wired with 0.08-0.5 mm² stranded cable to ensure robust PROFIBUS link integrity. An onboard RS 232 serial interface at the X2 port facilitates diagnostics, parameterization, and firmware updates during commissioning and service operations. Rated for factory-floor environments, the unit must remain dry and is designed to withstand normal thermal loads, though its housing may become hot during extended operation. Bosch Rexroth enforces a one-year warranty on this section, safeguarding your investment against manufacturing defects.



Installation and handling guidelines stipulate that only authorized personnel may manipulate the electrical connection points when powered off. The CSB01.1C-PB-ENS-ENS-L2-S-NN-FW delivers consistent drive control and motor monitoring in applications ranging from packaging machines to CNC systems. With its configurable I/O, advanced encoder support, and PROFIBUS master capabilities, this drive controller section provides a reliable, field-proven platform for industrial automation deployments worldwide.

Technical Specifications

Configuration Option
Configurable

Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL

Encoder Option 2
IndraDyn / Hiperface / 1 Vpp / TTL

Master Communication
PROFIBUS

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSB01.1C-PB-ENS-ENS-L2-S-NN-FW.
