CSB01.1C-PL-ENS-MA1-L2-S-NN-FW

CSB Drive Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The CSB01.1C-PL-ENS-MA1-L2-S-NN-FW from Bosch Rexroth Indramat is part of the CSB Drive Controllers lineup and features a Configuration Option configurable control section designed for flexible integration. It operates with a Master Communication parallel interface and supports both Encoder Option 1 IndraDyn/Hiperface/1Vpp/TTL and Encoder Option 2 Analog I/O extension for precise feedback. Power is supplied via a dedicated 24 V DC input from the paired power section, while three module slots accommodate user-selected expansions. The unit ships with three preinstalled modules ready to deploy and plugs directly into compatible power sections for streamlined installation.



The preinstalled modules include an encoder IndraDyn interface with full Hiperface support, an analog I/O extension board for additional signal handling, and a dedicated safety module that implements safe torque off (STO) to immediately disable drive outputs and prevent motor shaft rotation. An integrated RS-232 interface on the front panel enables direct serial communication for diagnostics and firmware updates. External I/O and module slots are clearly accessible on the front bezel, and all connections are identified by a robust type plate listing the hardware type code and serial number. Front-of-panel status LEDs and keyed connectors simplify commissioning and reduce error risk during maintenance.



Installation and handling of the CSB01.1C-PL-ENS-MA1-L2-S-NN-FW must be performed by qualified personnel to ensure compliance with safety standards. The controller can be shipped globally and is backed by a one-year warranty, guaranteeing support and reliability in demanding automation environments.

Technical Specifications

Configuration Option
Configurable

Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL

Encoder Option 2
Analog I/O Extension

Master Communication
Parallel Interface
