The CSB01.1C-PL-ENS-NNN-L2-S-NN-FW, Bosch Rexroth Indramat, CSB Drive Controllers Servo Drive is a configurable single-axis control section within the IndraDrive system. It features a Parallel Interface for master communication and supports the BASIC UNIVERSAL range of power modules. The unit plugs directly into compatible power sections and leverages Bosch Rexroth’s proven IndraDrive architecture for tight, responsive motion control. Its robust design ensures precise servo regulation under demanding industrial conditions.
Designed to accommodate a wide array of encoder systems, this controller accepts an IndraDyn/Hiperface/1Vpp/TTL input and reserves an Encoder Option 2: Not an option slot for future expansions. It provides 16 digital inputs and 16 digital outputs, organized in groups of 4, and delivers a 12 V support voltage for encoder electronics. Safety is ensured by the Safe Torque Off function meeting Category 3 PL e/SIL 3 requirements, while firmware for advanced features is available as a separate order item. A standard user panel with a single-line display and four keys offers real-time diagnostics and parameter navigation. Additional specifications include its Configurable architecture and global shipment with a one-year warranty.
Engineers benefit from seamless integration into existing CSB Drive Controller installations, leveraging common parameter sets and diagnostics across multi-axis systems. The unit’s IP20-rated, category C3 enclosure protects against electromagnetic interference in industrial environments. Backed by Bosch Rexroth Indramat’s service network, the CSB01.1C-PL-ENS-NNN-L2-S-NN-FW delivers reliable, high-performance motion control for packaging machines, conveyors, and precision manufacturing cells.
Configuration Option
Configurable
Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL
Encoder Option 2
Not an option
Master Communication
Parallel Interface
