The Bosch Rexroth Indramat CSB01.1C-S3-ENS-EN2-L2-S-NN-FW from the CSB Drive Controllers series combines robust design with advanced communication and encoder interfaces. This CSB01.1C-S3-ENS-EN2-L2-S-NN-FW unit features a Master Communication: SERCOS III interface that delivers highly precise, deterministic control for demanding motion applications. The drive is fully Configurable for tailored solutions and supports both Encoder Option 1: IndraDyn/Hiperface/1Vpp/TTL and Encoder Option 2: EnDat 2.1/1Vpp/TTL feedback systems. Its modular architecture enables flexible integration into existing automation environments.
The control section of this servo drive is engineered to support a wide range of industrial encoders, accommodating 5 V and 12 V supply voltages for maximum compatibility. With SERCOS III as the native fieldbus, the controller ensures real-time data exchange and synchronization with up to 8 kHz pulse-width modulation frequency. The Configurable option allows selection of encoder variants and communication modules to match application requirements precisely. Combined with safety features and a compact footprint, this unit optimizes panel space and simplifies wiring.
Operational safety is assured by the integrated Safe Torque Off module rated to category 3 PL e/SIL 3, preventing unintended motor torque generation. Commissioning and diagnostics are streamlined via a standard control panel with single-line display, while remote setup is supported by the IndraWorks software package. Global shipping is backed by a one-year warranty, ensuring reliable deployment and service support for machine builders and system integrators.
Configuration Option
Configurable
Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL
Encoder Option 2
EnDat 2.1/1Vpp/TTl
Master Communication
SERCOS III
