CSB01.1C-S3-ENS-ENS-NN-S-NN-FW from Bosch Rexroth Indramat delivers advanced performance in the CSB Drive Controllers lineup. Engineered by Bosch Rexroth Indramat to the highest industrial quality standards, this servo drive controller enables precise motion control across a wide range of processing and production machinery. Its rugged design and comprehensive diagnostic interfaces ensure consistent throughput under demanding conditions. Operators must follow the user manual closely to avoid unintended motor movements and maintain safe, uninterrupted operation.
At the heart of the CSB01.1C-S3-ENS-ENS-NN-S-NN-FW lies a Master Communication interface via SERCOS III for deterministic, high-speed synchronization with upstream controllers. Configuration is fully Configurable through spring and screw terminals offering flexible I/O assignments. Dual encoder support accommodates both Encoder Option 1: IndraDyn/Hiperface/1Vpp/TTL and Encoder Option 2: IndraDyn/Hiperface/1 Vpp/TTL, streamlining integration with legacy and next-gen feedback systems. The drive maintains a nominal Power Consumption: 8 W draw with an Inrush Current: 4.5 A and a Max Pulse Width: 110 ms for reliable startup performance. Its robust enclosure houses metal components making the Weight: 11 kg controller both durable and fully recyclable at end of life.
Designed for seamless cabinet integration, the CSB01.1C-S3-ENS-ENS-NN-S-NN-FW excels in applications demanding continuous, high-precision motion. Its conformance to industrial safety and environmental standards, free of mercury and asbestos, underpins long-term reliability and regulatory compliance. Bosch Rexroth Indramat’s global support network and Wake Industrial’s one-year warranty further reduce commissioning time and total cost of ownership in servo-driven automation systems.
Configuration Option
Configurable
Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL
Encoder Option 2
IndraDyn / Hiperface / 1 Vpp / TTL
Master Communication
SERCOS III
