The Bosch Rexroth Indramat CSB01.1C-SE-ENS-ENS-NN-S-NN-FW drive controller from the CSB Drive Controllers series features a Configurable configuration option and high-speed SERCOS Interface master communication. This single-axis control section measures 49.5 mm x 103 mm x 241 mm and is designed for seamless integration into compact panels. Its lightweight design simplifies installation and transportation, while a single-line LED display provides clear operational feedback. The unit requires a stable power source and a protective diode to safeguard against polarity reversal and accidental misconnection.
Reliable motion control is delivered through dual Encoder Option 1: IndraDyn/Hiperface/1Vpp/TTL and Encoder Option 2: IndraDyn/Hiperface/1Vpp/TTL interfaces, ensuring compatibility with a broad range of feedback devices. Commissioning engineers can tailor the control section via four front-panel keys, adjusting parameters to suit diverse load profiles. Firmware is supplied separately by the distributor and must be ordered as a subitem to match the designated type code. The module supports industry-standard encoder evaluation features for IndraDyn and Hiperface protocols, guaranteeing precise position and speed regulation.
Engineered for industrial environments, the CSB01.1C-SE-ENS-ENS-NN-S-NN-FW incorporates a robust PCB layout with overvoltage and short-circuit protection built in. The horizontal mounting surface must remain free of oil, grease, and debris to maintain optimal heat dissipation. Global shipping is backed by a one-year warranty through Wake Industrial, ensuring long-term service and technical support for critical automation applications.
Configuration Option
Configurable
Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL
Encoder Option 2
IndraDyn / Hiperface / 1 Vpp / TTL
Master Communication
SERCOS Interface
