The Bosch Rexroth Indramat CSB01.1C-SE-ENS-MEM-L2-S-NN-FW from the CSB Drive Controllers series is a highly adaptable control section designed for sophisticated motion applications. It features a Configuration Option configurable architecture and supports dual Encoder Option 1 IndraDyn/Hiperface/1Vpp/TTL as well as Encoder Option 2 encoder emulation. Communication is handled via a native Master Communication SERCOS Interface and a front-panel RS-232 serial interface for diagnostics and parameterization. This modular unit accepts two optional plug-in modules plus a dedicated safety module, delivering both functional versatility and enhanced protection.
Assembly and maintenance protocols for the CSB01.1C-SE-ENS-MEM-L2-S-NN-FW mandate that only certified personnel perform the coupling of control and power sections. Bosch Rexroth recommends limiting the assembly/disassembly cycle to 20 times to maintain mechanical integrity and ensure reliable operation. The integrated safety module provides safe torque off functionality, meeting stringent machine safety standards. Configuration and commissioning are streamlined through a standard control panel, while separate ordering of firmware and power sections allows tailored system builds.
Optimized for machine tools, printing presses, processing lines, and handling systems, this control section excels in environments that demand precision and uptime. Its modular design accommodates rapid upgrades, and the combination of IndraDyn encoder and emulation modules simplifies encoder replacement and testing. Shipped globally with a one-year warranty, the CSB01.1C-SE-ENS-MEM-L2-S-NN-FW ensures sustained performance under the ambient conditions specified by Bosch Rexroth Indramat.
Configuration Option
Configurable
Encoder Option 1
IndraDyn/Hiperface/1Vpp/TTL
Encoder Option 2
Encoder Emulation
Master Communication
SERCOS Interface
