R911307293 (CSB01.1C-PB-ENS-MA1-L1-S-NN-FW)

CSB Drive Controllers

CSB01.1C-PB-ENS-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 30 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911307293 (CSB01.1C-PB-ENS-MA1-L1-S-NN-FW) is a configurable control section for drive controllers used in machine tools. It complies with EN 60204-1 standards and features an X41 connection point equipped with starting lockout safety using a 9-pole female D-Sub connector. This unit supports PROFIBUS master communication and provides five to eight digital inputs, three of which are configurable as digital outputs. It integrates the MA1 module for expanded analog input/output capability and supports encoder input options for IndraDyn, Hiperface, 1Vpp, and TTL. The control section operates at 8W, 24VDC, and requires isolated power supplies for I/O at X31 and X32 connectors. A cooling period of at least 15 minutes is required post-operation.

Technical Specifications

Cool Down Time
15 minutes

Use
Machine Tools

Communication Module
PROFIBUS master

Terminating Resistor
Connectable and active at first and last bus nodes

Digital Inputs
5 to 8

Combined I/O
3

Extra Modules
MA1 for expanding analog inputs and outputs

Power Consumption
8W at 24VDC

Inputs/Outputs
Isolated at X31 and X32

Analog Input and Output Resolution
12 bits

Analog Input and Output Voltage Rating
+/-10V

Transportation
Well-known logistics team such as FedEx or DHL.
