R911307294 (CSB01.1C-PL-ENS-MA1-L1-S-NN-FW)

CSB Drive Controllers

CSB01.1C-PL-ENS-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 34 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911307294 (CSB01.1C-PL-ENS-MA1-L1-S-NN-FW) is a digital control section designed for single-axis IndraDrive controllers. This unit provides a parallel interface and includes 16 galvanically isolated digital inputs and outputs, organized into four groups, each requiring a 24 V DC supply. It features three modular slots: two are configurable for either analog I/O extension or IndraDyn encoder modules, with Hiperface, 1Vpp, and TTL encoder compatibility; the third slot accommodates a safety module with starting lockout. The device employs convection cooling, supports an operating temperature of 0 to 40°C, and is suitable for use at altitudes from 0 to 1000 meters. Installation and operation should only be performed by trained and certified personnel. Hot swapping of the control panel is not supported; power must be disconnected during any removal or installation.

Technical Specifications

Master Communication Interface
Parallel interface

Number of Digital Inputs
16

Number of Digital Outputs
16

Power Supply
24 Volts DC

Safety Module Slots
1

Optional Module Slots
2

Optional Modules
Analog I/O extension and encoder IndraDyn

Encoder Protocol
Hiperface

Configurable
Yes

Control Panel
Standard

Hot Swap Support
No

Cooling Method
Convection cooled

Operating Temperature
0 to 40 degrees Celsius

Installation Site Altitude
0 to 1000 meters

Storage Temperatue
-20 to 70 degrees Celsius

Shipping
Global
