R911314840 (CSB01.1C-S3-ENS-EN1-L1-S-NN-FW)

CSB Drive Controllers

Rated 4.1 stars (5 total reviews)
  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 19 Seconds

The Bosch Rexroth R911314840 (CSB01.1C-S3-ENS-EN1-L1-S-NN-FW) is a control section module within the CSB01 series, engineered for integration with the IndraDrive system. It features SERCOS III master communication based on the IEEE 802.3 standard to support precise motion control applications. The unit accommodates multiple encoder types, including 5V-TTL, IndraDyn, Hiperface, 1Vpp, and HSF/RSF interfaces, supporting both 12V and 8V DC encoders. An evaluation interface for Resolver and HSF encoders is included, rated for 8V DC or 18.2V peak-peak. Configurable via IndraWorks software, the component provides diagnostics, error memory access, and starting lockout safety according to EN 60204-1 stop category 0. The maximum recommended operating temperature is 45°C.

Technical Specifications

Product Type
Single-Axis Control Section

Communication Module
Sercos III

Encoder Interface Voltage
12V

Additional Encoder Interface
Resolver and HSF encoder evaluation interface

Additional encoder Interface Supply Voltage
DC 8V or AC 18.2V peak-peak

Safety Module
Starting lockout

Compliance
Stop category 0 according to EN 60204-1

Control Panel
Standard

Commissioning Software
IndraWorks for PC

Firmware
Supported (ordered separately)

Maximum Ambient Temperature
45oC
