R911329918 (CSB01.1C-PL-ENS-EN2-L2-S-NN-FW)

CSB Drive Controllers

CSB01.1C-PL-ENS-EN2-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 24 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth CSB01.1 control section, MPN R911329918 (CSB01.1C-PL-ENS-EN2-L2-S-NN-FW), is a configurable drive controller for industrial automation applications. It features three digital outputs, eight digital inputs, two probe ports, and supports control cycle timings of 125 μs for current, 250–500 μs for speed, and 500–1000 μs for position regulation. This unit incorporates a diode for polarity protection, L2 safety options, and supports master communication via parallel interface. Encoder interfaces include IndraDyn, Hiperface, 1Vpp/TTL, and EnDat 2.1. The CSB01.1 integrates with IndraDrive C Series converters and measures 103 mm (depth) × 49.5 mm (width) × 241 mm (height).

Technical Specifications

Digital Outputs
3

Digital Inputs
8

Probe Ports
2

Current Control Cycle
125 microseconds

Speed Control
250-500 microseconds

Position Control
500-1000 microseconds

Manufacturing Procedure
Energy- and Resource-efficient

Environmentally Friendly Material Use
Yes

Voltage and Current Limits
Safe levels to be maintained

Misconnection Protection
Diode Usage

Safety Option
L2

Communication
Parallel Interface Master

Depth
103mm

Width
49.5mm

Height
241mm

Option 1 Encoder
IndraDyn/Hiperface

Interface
RS232 Serial

Software Compatibility
Rexroth-approved Software

Option 2 Encoder
EnDat2.1

Control Panel
Simple and Modifiable

Global Shipping
Available
