The DKR02.1-W300N-BE02-00 drive controller from Bosch Rexroth Indramat belongs to the DKR Drive Controllers series. It delivers a nominal current rating of 300 A, uses an air-cooled built-in blower, communicates via a SERCOS interface, and features an IP20 protection rating. This modular unit supports digital servo and resolver feedback and accepts plug-in cards to extend functionality. It ships globally with a one-year warranty.

Technical Specifications

Bleeder Configuration
No bleeder/ Without brake chopper, rigid DC bus

Command Interface
SERCOS interface

Cooling Method
Air (built-in blower)

Design Version
1

Line Series
02

Function Numeric Code
02

Motor Feedback
Digital servo and resolver feedback

Product Series
DKR

Current Rating
300

Nominal Current
Approx 300A

Function Numeric Version
00
