R911270306 (DKR03.1-W200N-BE24-01-FW)

Name: R911270306 (DKR03.1-W200N-BE24-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W200N-BE24-01-FW
Price: 372.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911270306 (DKR03.1-W200N-BE24-01-FW) is a drive controller from the Bosch Rexroth Indramat DKR series, designed for use in industrial control systems. This unit is rated for a continuous current of 200A, utilizes air cooling via a built-in blower, and features a rigid DC bus configuration without a bleeder or brake chopper. It supports both internal and external loop control and can manage high-resolution motor feedback up to 1/4,000,000 of a revolution using digital servo and resolver feedback. Communication is enabled through a built-in SERCOS interface. The unit corresponds to design version 1 and line series 03 within the DKR product range.

Technical Specifications

Line Version
03

Design Version
1

Cooling Mode
Air (Built-in Blower)

Rated Current
200A

Design
Standard Without Bleeder

Feedback
Digital Servo and Resolver

Command Communication
SERCOS Interface

Function Numeric Code
24

Version
01

Frequently Asked Questions

Is the DKR03.1-W200N-BE24-01-FW equipped with a brake chopper?

No, the DKR03.1-W200N-BE24-01-FW is not constructed with a built-in brale chopper.

What is the rated output current for the DKR03.1-W200N-BE24-01-FW?

The DKR03.1-W200N-BE24-01-FW provides an output of 200 A, ensuring robust performance in demanding applications.

What feedback options does the DKR03.1-W200N-BE24-01-FW support?

The DKR03.1-W200N-BE24-01-FW supports digital servo feedback and resolver feedback for versatile integration.

What interface does the DKR03.1-W200N-BE24-01-FW support?

The DKR03.1-W200N-BE24-01-FW comes with a SERCOS interface for seamless system integration.

Does the DKR03.1-W200N-BE24-01-FW come with a built-in fan?

Yes, the DKR03.1-W200N-BE24-01-FW comes with a blower for thermal management, ensuring operational stability.

Common Misspellings

DKR031W200NBE2401

DKR03 1 W200N BE24 01

dkr03.1-w200n-be24-01

DKR031W200NBE2401

DKR03 1 W200N BE24 01

DKR3.1-W200N-BE24-01-FW

Internal Product Review

The DKR03.1-W200N-BE24-01-FW is a robust controller with reliable performance. It has a high output capacity, but its lack of braking features may be a con in some setups.
