The R911276159 (DKR03.1-W100N-BE31-01-FW) is a Rexroth Indramat servo drive controller engineered for integration with AC spindle motors (2AD, ADF), linear motors (LSF, LAF), and frameless spindle motors. This unit features a rated current of 100A and supports a three-phase AC input voltage of 400 to 480V at 50 to 60Hz, with 200VA control voltage power. It utilizes a SERCOS command interface, accommodates digital servo and resolver feedback, and is constructed with an integrated mains contactor and emergency stop shutdown device. The controller does not include a bleeder resistor or brake chopper, instead relying on a rigid DC bus and active heat dissipation via a built-in air blower and heatsink. Design and function versions are marked as Version 1 for both.

Technical Specifications

Voltage Input Connection
Three-phase

Integrated Systems
Mains contactor, Emergency stop shutdown device

Rated Current
100Amperes

Cooling Systems
Air blower, Heatsink

Feedback System
Digital servo and resolver

Command Communication Interface
SERCOS

Rated Power Voltage
3xAC 400 to 480volts

Power Input Frequency
50 to 60 Hartz

Control Voltage
AC230Volts

Control Voltage Power
200volts-Amperes

Peak Current
71Amperes

Peak Power Output
26 Kilowatts

Peak Regenerated Power
26Kilowatts

Frequently Asked Questions

Does the DKR03.1-W100N-BE31-01-FW motor drive support mixed feedback signals in dual encoder configurations?

Yes, the drive can process combined resolver and digital encoder signals, enabling hybrid feedback loops that improve motion accuracy and dynamic response.

What type of protection schemes exist in the Bosch Rexroth Indramat DKR03.1-W100N-BE31-01-FW drive motor system?

Integrated protection covers overcurrent, thermal overload, DC bus integrity, and feedback loss, ensuring safe shutdown under irregular operating conditions.

Where are typical mounting locations for the DKR03.1-W100N-BE31-01-FW drive motor within industrial cabinets?

It is mounted vertically with enforced ventilation clearance, ensuring unobstructed cooling airflow and reliable electrical interconnection with supply lines.

Does Bosch Rexroth Indramat DKR03.1-W100N-BE31-01-FW provide modular serviceability for critical components?

Yes, its modular structure allows replacement of IGBT stages, fans, and control boards, minimizing downtime during service interventions.

What communication cycle times are achievable on the SERCOS interface with the DKR03.1-W100N-BE31-01-FW drive motor?

Cycle times down to microsecond resolution enable precise drive synchronization, maintaining tight motion coordination in multi-axis automation.

Common Misspellings

DKR031W100NBE3101FW

DKR03 1 W100N BE31 01 FW

dkr03.1-w100n-be31-01-fw

DKR3.1-W100N-BE31-01-FW

Internal Product Review

The DKR03.1-W100N-BE31-01-FW drive controller belongs to the DKR series of Bosch Rexroth Indramat. It has a rigid DC bus without bleeder and air cooling through a built-in blower. This drive is applied in trackers, solar installations and HVAC systems where precise current regulation of 100 A is required.
