R911279013 (DKR04.1-W400N-BE34-02-FW)

DKR Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 17 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911279013 (DKR04.1-W400N-BE34-02-FW) is a drive controller from the DKR04 series, designed for high-performance industrial automation. It operates with a rated current of 400 A and incorporates a base unit without plug-in cards. The device includes a firmware module for parameter storage, a SERCOS command interface, and supports digital servo or resolver motor feedback. Cooling options include ducted, internal, or external air; for external air cooling, an M1-RAC4 frame with cabinet vents is recommended. The model omits a brake chopper (bleeder) and uses a rigid DC bus. Maximum pressure is 390 Pa and minimum airflow is 360 m³/h. Noise emission levels are 76.1 dB(A) at 50 Hz and 75.6 dB(A) at 60 Hz. Electrical connections must be made according to safety standards.

Technical Specifications

Component
Drive Controller

Command Interface Card
SERCOS

Bleeder
None

Rated Current
400

Cooling Method
Duct/Air from inside or outside of the cabinet

Mounting Frame Requirement
M1-RAC4 (when using outside air for cooling)

Energy Dissipation
Dependent on load

Maximum Pressure
390Pa

Minimum Air Flow
360 m3/h

Noise Emission @ 50Hz
76.1db(A)

Noise Emission @ 60Hz
75.6db(A)

Shipping
Global

Electrical Connections
Proper Wiring Required
