R911281338 (DKR03.1-W100N-BE56-01-FW)

Name: R911281338 (DKR03.1-W100N-BE56-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W100N-BE56-01-FW
Price: 620.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911281338 (DKR03.1-W100N-BE56-01-FW) is a BOSCH Rexroth DKR series drive controller engineered for operation of AC motors in environments such as printing and machining. It is configurable via standalone plug-in modules inserted into slots on the controller chassis. The unit features IP20 protection per IEC 529/EN 60529, supports a rated current of 100 A, and is equipped with a SERCOS interface for command input. The controller operates at 50-60 Hz with natural convection and a built-in blower for heat dissipation, typically releasing 1200 W during operation. The device functions optimally between ambient temperatures of 5°C and 45°C, and incorporates digital servo and resolver feedback. There is no internal bleeder or brake chopper; the DC bus is rigid. At least a 5-minute discharge interval is required after shutdown for the internal capacitors.

Technical Specifications

Product Type
Drive Controller

Use
Controlling AC Motors

Protection Rating
Class IP20

Operational Temperature
5 to 45 degrees C

Power Disconnect Time
5 minutes

Heat Dissipation
1200 watts

Convection Method
Natural

System Frequency
50-60Hz

Shipping Availability
Global

Industrial Usage
Printing and Machining Tools

Frequently Asked Questions

Where is the motor feedback evaluation executed inside the Bosch Rexroth Indramat DKR03.1-W100N-BE56-01-FW?

The evaluation is embedded in the digital control kernel, ensuring resolver and digital encoder alignment to maintain closed-loop integrity in demanding aerospace control systems.

What isolation principles are used in the Bosch Rexroth Indramat DKR03.1-W100N-BE56-01-FW motor control stage?

It uses galvanic isolation between control electronics and power stages, safeguarding sensitive resolver circuits against high-voltage disturbances from the rigid DC bus.

How does the Bosch Rexroth Indramat DKR03.1-W100N-BE56-01-FW motor protection operate without brake chopper support?

The design manages regenerative energy through DC bus stiffness, requiring external dissipation arrangements in load scenarios, which protects motor windings from voltage excursions.

Does the Bosch Rexroth Indramat DKR03.1-W100N-BE56-01-FW motor resolver feedback compensate thermal drift?

Yes, thermal drift is normalized within the drive’s interpolation logic, preventing feedback deviation and securing motor axis alignment under fluctuating aerospace environmental conditions.

What function does the Bosch Rexroth Indramat DKR03.1-W100N-BE56-01-FW motor’s digital SERCOS link serve?

It establishes deterministic command transmission, synchronizing multiple axes with high fidelity, ensuring aircraft automation tasks remain coordinated and free from jitter.

Common Misspellings

DKR031W100NBE5601FW

DKR03 1 W100N BE56 01 FW

dkr03.1-w100n-be56-01-fw

DKR3.1-W100N-BE56-01-FW

Internal Product Review

The Bosch Rexroth Indramat DKR03.1-W100N-BE56-01-FW drive from the DKR series is a high-reliability servo control unit. It features SERCOS command interface, air cooling with built-in blower, and resolver plus digital feedback. It is widely applied in aircraft manufacturing automation, robotic handling, and aerospace precision testing systems.
