R911285219 (DKR03.1-W200B-BT04-01-FW)

Name: R911285219 (DKR03.1-W200B-BT04-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W200B-BT04-01-FW
Price: 334.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Indramat MPN R911285219 (DKR03.1-W200B-BT04-01-FW) is a drive controller designed for machine tools and printing machines utilizing 2AD or ADF main spindle motors. It offers a power output range of 10–93 kW, control voltage power of 200 VA, and operates on 3-phase 400–480 V AC at 50–60 Hz. The controller features a main contactor, emergency stop device, and integrated air cooling via a built-in blower. Digital control is achieved through firmware FWA-DIAX03, supporting interfaces such as SERCOS, Profibus, and INTERBUS. It accommodates resolver and digital servo feedback, incorporates a bleeder unit, and conforms to IP20 EN60529/IEC529 protection. The unit functions within temperature limits of +5°C to +45°C and elevations up to 1000 m.

Technical Specifications

Power Output
Continuous between 10 to 93kW

Speed
Broad range

Primary Direct Connection
Grounded AC

Control Voltage Power
200 VA

Rated Power
3*AC 400V-480V

System Frequency
50-60Hz

Features
Main contractor, emergency stop shutdown device

Optional Brake Resistor
Requires 150kWs braking energy

Cooling Method
Built-in blower

Firmware
FWA-DIAX03

Protection Category
IP 20 per EN60529/IEC529

Ambient Temperature
+5°C to +45°C, permissible to +55°C

Mounting Elevation
Should not exceed 1000 meters above sea level

Shipping
Global.

Frequently Asked Questions

What is the primary drive current handling capacity of Bosch Rexroth Indramat DKR03.1-W200B-BT04-01-FW?

The drive supports a rated current of 200A, enabling it to manage heavy industrial drive loads with sustained stability and reliable continuous operation in demanding conditions.

How does Bosch Rexroth Indramat DKR03.1-W200B-BT04-01-FW manage thermal balance during drive operation?

It utilizes air cooling via integrated blower fans, maintaining regulated airflow across internal power modules to avoid overheating under prolonged operational duty cycles.

Does Bosch Rexroth Indramat DKR03.1-W200B-BT04-01-FW include a built-in bleeder for drive discharge?

Yes, it features a with-bleeder design, allowing safe dissipation of regenerative drive energy and stabilizing DC link voltage under fluctuating load conditions.

What operational safety mechanisms are embedded in Bosch Rexroth Indramat DKR03.1-W200B-BT04-01-FW?

The unit integrates fault monitoring, thermal overload supervision, and safe discharge bleeder systems, ensuring protective drive shutdown under abnormal load or supply conditions.

Does Bosch Rexroth Indramat DKR03.1-W200B-BT04-01-FW allow modular firmware upgrades for drive operations?

Yes, its Function Numeric Version 01 ensures firmware upgrades align with Bosch Rexroth’s defined compatibility standards for enhanced drive feature sets.

Common Misspellings

DKR031W200BBT0401FW

DKR03 1 W200B BT04 01 FW

dkr03.1-w200b-bt04-01-fw

DKR3.1-W200B-BT04-01-FW

Internal Product Review

The Bosch Rexroth Indramat DKR03.1-W200B-BT04-01-FW drive controller from the DKR series provides industrial-grade motion control reliability. It offers 95% humidity bearing, SERCOS command interface and air-cooling mechanism. This drive controller suits automation systems, high-speed machining centers, and precision applications requiring accurate feedback control.
