R911287164 (DKR03.1-W200N-BE05-03-FW)

DKR Drive Controllers

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 39 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911287164 (DKR03.1-W200N-BE05-03-FW) is a DKR series drive controller designed by Bosch Rexroth for applications requiring high discharge and high voltage current such as in printing machinery. It supports a rated current of 200A and operates on a power voltage of 0 to 380V at 50 to 60Hz. The unit features an internal blower for air cooling, supports digital servo and resolver feedback, and includes a SERCOS command interface. The controller is configured without a bleeder or brake chopper, uses a rigid DC bus, and is designed for installation by qualified personnel. Operating temperature is specified up to 55°C, and permanent grounding before power activation is required due to leakage current exceeding 3.5mA. Environmental and connection safety protocols must be followed to prevent hazardous motions and electrical risks.

Technical Specifications

Firmware
To be ordered separately

Installation Method
Specified

Function
Only with approved parts/accessories

System Frequency
50 to 60Hz

Cooling Method
Air circulation with inbuilt blower

Application
Printing Machines

Discharge Current
High

Voltage Current
High

Assembly
Qualified Personnel only

Usage
Commercial Machinery only

Leakage Current
More than 3.5mA

Rated Current
200A

Power Voltage
0 to 380V

Maximum Ambient Temperature
55C (Nominal data derated to 80%)

Shipping
Worldwide Destination Possible.
