R911287170 (DKR03.1-W100N-BA05-01-FW)

Name: R911287170 (DKR03.1-W100N-BA05-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W100N-BA05-01-FW
Price: 417.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911287170 (DKR03.1-W100N-BA05-01-FW) is a DKR series drive controller engineered for precise digital motor control. It operates with a power supply of 3xAC 400-480 V ±10%, delivering a maximum current of 71 A and supporting a rated current of 100 A. Dissipating up to 900 W of heat via a built-in blower and heat sink, it is capable of withstanding up to 150 kW of energy dissipation through its internal brake resistor during mains failure. The unit features an analog command interface, supports both resolver and digital servo feedback, and is configured without a brake chopper (rigid DC bus). It weighs approximately 49 kg and is designed for operation at ambient temperatures from +5°C to +45°C at full capacity, with reduced operation up to +55°C at 80% capacity. Adherence to all provided safety and technical documentation is required during installation and use.

Technical Specifications

Product Type
Intelligent Drive Controller

Speed Range
Broad

Control Level
High

Power Dissipation
900W

Voltage Rating
3xAC 400-480 V ±10%

Maximum Current
71 Amps

Weight
49 kg

Temperature Range (100% Rated Data)
+5 to +45 degrees

Temperature Range (80% Rated Data)
+55 degrees

Maximum Elevation (100% Rated Data)
0 to 1000 meter/sea level

Command Interface
Analog

Feedback System
Resolver Motor and Digital Servo

Function Numeric Code
05

Bleeder
Not included

Frequently Asked Questions

How does the rigid DC bus affect energy return in Bosch Rexroth Indramat DKR03.1-W100N-BA05-01-FW motor systems?

It prevents uncontrolled regeneration, stabilizing voltage without bleeder dissipation, ideal for grid-connected applications needing stable bus management.

Where is the DKR03.1-W100N-BA05-01-FW motor utilized in construction machinery automation?

It is used in heavy-duty cranes, drilling machines, and automated lifts, delivering consistent torque regulation and motion precision.

What are the firmware implications of DKR03.1-W100N-BA05-01-FW motor design?

The FW specification denotes firmware compatibility, ensuring proper communication, command execution, and error-handling between drive and controllers.

How does the Bosch Rexroth Indramat DKR03.1-W100N-BA05-01-FW motor handle fluctuating renewable energy inputs?

It adjusts torque in real-time using resolver feedback, accommodating inconsistent mechanical loads like varying wind gusts or solar panel shifts.

Does the DKR03.1-W100N-BA05-01-FW motor support parallel operation with other drives?

Yes, it supports synchronized parallel operation with coordinated feedback loops, ensuring balanced load distribution across multiple axes.

Common Misspellings

DKR031W100NBA0501FW

DKR03 1 W100N BA05 01 FW

dkr03.1-w100n-ba05-01-fw

DKR3.1-W100N-BA05-01-FW

Internal Product Review

The Bosch Rexroth Indramat DKR03.1-W100N-BA05-01-FW servo drive from the DKR series ensures motor control and reliability in industrial systems. It features air cooling with built-in blower and versatile digital servo/resolver feedback. It includes uses in power generation plants, renewable energy systems, automated grid management and construction industry automation.
