R911289884 (DKR03.1-W100N-BT04-01-FW)

Name: R911289884 (DKR03.1-W100N-BT04-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W100N-BT04-01-FW
Price: 414.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth drive control unit R911289884 (DKR03.1-W100N-BT04-01-FW) is designed for industrial automation applications, featuring a SERCOS command interface and five programmable plug-in slots. It is configured without a bleeder or brake chopper, utilizing a rigid DC bus and incorporates an air-cooling system via a built-in blower. Operating on three-phase AC power at 400–480 V with a control voltage of AC 230 V (power consumption 200 VA), this unit supports digital servo and resolver feedback. It provides a rated current of 100 A, achieves peak regenerated power of 26 kW for up to 10 seconds, continuous regenerated power of 22 kW, and peak current of 71 A. The device is IP20 rated, suitable for operation up to +55°C, weighs 49 kg, and dissipates 900 W of heat. Auxiliary brake resistor support is included; software must be sourced separately.

Technical Specifications

Function Numeric Code
04

Version Function Numeric Code
01

Communication Interface
SERCOS

Cooling Method
Air, Build-in Blower

Basic Unit
DKR03.1-W100-B with 5 Plug-in Slots

Input Voltage
3-phase AC 400 to 480V

Control Voltage
AC 230 V

Operating Frequency
50/60 Hz

Control Voltage Power
200 VA

Peak Regenerated Power
26 kW for 10 seconds

Continuous Regenerated Power
22 kW at 71 A peak current

Maximum Permissible Temperature
+55 ͦC

Protection Class
IP20

Net Weight
49 kg

Heat Dissipation
900 W at continuous current, 600 W in air channel

Software Notes
Must order separately

Frequently Asked Questions

Does Bosch Rexroth Indramat DKR03.1-W100N-BT04-01-FW motor controller offer phase imbalance detection?

Yes, it continuously measures all three AC input phases, shutting down operation on detection of imbalance or asymmetrical supply to protect the motor.

What motor shaft feedback devices can be interfaced with Bosch Rexroth Indramat DKR03.1-W100N-BT04-01-FW?

It supports multiple encoder formats through plug-in modules, including TTL incremental, absolute encoders, and SERCOS digital encoders for closed-loop positioning.

Where is the control voltage of Bosch Rexroth Indramat DKR03.1-W100N-BT04-01-FW motor applied within system architecture?

The 230 V AC control voltage powers internal logic, cooling blowers, and protective circuits, ensuring stable operation independent of main three-phase input voltage.

Does Bosch Rexroth Indramat DKR03.1-W100N-BT04-01-FW motor controller enable multiple drive coordination?

Yes, through SERCOS interface it supports synchronous axis coordination, enabling complex CNC and robotics tasks requiring deterministic multi-axis timing.

What is the permissible grounding scheme for Bosch Rexroth Indramat DKR03.1-W100N-BT04-01-FW motor installations?

A TN-S or TT grounding system with shielded cabling is recommended, preventing EMI propagation and ensuring safe discharge of leakage currents during operation.

Common Misspellings

DKR031W100NBT0401FW

DKR03 1 W100N BT04 01 FW

dkr03.1-w100n-bt04-01-fw

DKR3.1-W100N-BT04-01-FW

Internal Product Review

The DKR03.1-W100N-BT04-01-FW drive controller by Bosch Rexroth Indramat comes from the series DKR. It features a 3-phase AC input of 400–480 V and regenerative power handling of 26 kW. This unit is ideal for automation systems and motion control solutions where efficiency, cooling stability and reliable drive performance are crucial.
