R911290817 (DKR04.1-W400N-BE74-02-FW)

DKR Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 24 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911290817 (DKR04.1-W400N-BE74-02-FW) is a Rexroth Indramat DKR series drive controller engineered for precise control of electrical motors. It delivers continuous drive power up to 93 kW at 4 kHz and 66 kW at 8 kHz, accepting a power voltage in the range of 0–380 V and supporting a peak current of 282 A. The unit features SERCOS interface command connectivity, digital servo and resolver feedback, and a rigid DC bus without a brake chopper. Cooling is provided by an integrated air blower, with heat generation of 2500 W. The controller operates within a 50–60 Hz frequency range, requires 300 VA control voltage power, and supports mounting at elevations from 0 to 1000 meters. It has a nominal current rating of 400 A, a weight of approximately 150 kg, and can increase by 1 to 7 kg with additional accessories.

Technical Specifications

Product Type
Drive Controller

Drive Power at 4kHz
93 kW

Drive Power at 8kHz
66 kW

Drive Controller Power Voltage
0-380 Volts

Heat Dissipation
2500 Watts

Cooling Mechanism
Integrated Air Blower

Weight of Unit
150 kilograms

Accessories Weight
1-7 kilograms

Operating Altitude
0-1000 meters

Peak Current
282 amperes

Frequency Range
50-60 Hz

Control Voltage Power
300 VA

Continuous Current at 4kHz
210 amperes

Continuous Current at 8kHz
150 amperes

Regenerative Power
66 kW

Control Voltage
230 Volts

Operating Temperature
5-45 degree celsius

Protection Category
IP 20

Shipping Availability
Global.
