The R911293520 (DKR02.1-W300N-BE45-01-FW) is a drive controller designed for precise regulation of AC main spindle motors such as 2AD or ADF, frameless spindle motors 1MB, as well as LAF or LSF linear motors. This unit supports SERCOS real-time communication for digitized information exchange within the servo system. The controller features digital servo and resolver feedback, a nominal current rating of approximately 300A, and operates at 230 V with a maximum power output of 93 kW. Physical dimensions are 1000 mm length and 400 mm width, with an increase of about 170 mm in length when using a cooling duct. Air cooling is implemented via a built-in blower. The design omits a bleeder and brake chopper, supports a rigid DC bus, and requires a minimum separation of 100 mm between power and feedback cables to prevent interference. Only qualified personnel should operate this equipment.

Technical Specifications

Communication Interface
Serial-Real-Time-Communication

Dimensions
1000mm(long) x 400mm(wide)

Cable Types
Power Cable, Motor Feedback Cable

Rated Current
300 Amperes

Rated Control Voltage
230 volts

Connection
Three-Phase Electrical Connector

Maximum Power Output from Motors
93 Kilowatts

Frequently Asked Questions

How does resolver feedback add value to the DKR02.1-W300N-BE45-01-FW system?

Resolver feedback works reliably in harsh environments. It ensures the drive can maintain stable performance even under electrical noise or temperature variations.

Why is the SERCOS interface used in this Bosch Rexroth Indramat drive?

The SERCOS interface enables high-speed, real-time communication between the drive and the controller. This improves synchronization and ensures efficient system performance.

What role does the line series ‘02’ play in this drive’s classification?

The line series ‘02’ identifies the product generation within the DKR family. It ensures the drive integrates with other components from the same series.

Why does the DKR02.1-W300N-BE45-01-FW include both servo and resolver feedback options?

Offering both options provides flexibility for different motor and application needs. Users can choose based on whether high precision or rugged reliability is more critical.

How does the design version ‘1’ impact the operation of the DKR02.1-W300N-BE45-01-FW?

Design version ‘1’ represents the base configuration for this product. It provides a standardized foundation while allowing compatibility with specific system requirements.

Common Misspellings

DKR021W300NBE4501FW

DKR02 1 W300N BE45 01 FW

dkr02.1-w300n-be45-01-fw

DKR2.1-W300N-BE45-01-FW

Internal Product Review

The DKR02.1-W300N-BE45-01-FW is a heavy-duty servo drive with internal blower cooling for guaranteed operation. It is designed by Bosch Rexroth Indramat and is utilized extensively in cutting-edge automation such as high-capacity pick-and-place machines and semiconductor wafer steppers. This drive controller features SERCOS interface communication and accommodates digital servo/resolver feedback.
