R911294063 (DKR04.1-W400E-BE74-02-FW)

Name: R911294063 (DKR04.1-W400E-BE74-02-FW)
Brand: Indramat Drives
SKU: DKR04.1-W400E-BE74-02-FW
Price: 782.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth drive, MPN R911294063 (DKR04.1-W400E-BE74-02-FW), is designed for industrial automation with peak output power of 125 kW at a maximum current of 282 A and operates on a control AC voltage of 230 V. It supports two continuous output levels: 93 kW at 4 kHz with 210 A, and 66 kW at 8 kHz with 150 A. The unit features external bleeder configuration with a brake chopper on a rigid DC bus, digital servo and resolver feedback, built-in air blower cooling, IP20 enclosure rating, SERCOS command interface, and a steady heat dissipation of 2500 W under nominal conditions.
