R911296422 (DKR03.1-W200N-BA09-01-FW)

Name: R911296422 (DKR03.1-W200N-BA09-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W200N-BA09-01-FW
Price: 199.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Rexroth Indramat MPN R911296422 (DKR03.1-W200N-BA09-01-FW) is a drive controller from the DKR series, suitable for use with industrial applications such as NC machine tools and printing machinery. It is compatible with 2AD/ADF AC main spindle motors, 1MB spindle motors, and LSF/LAF linear motors. The unit features an analog command interface and supports both digital servo and resolver feedback. Key specifications include a rated current of 200 A, a rigid DC bus without a brake chopper, built-in blower air cooling, protection class IP20, and installation up to 1000 meters altitude. Physical dimensions are 690 mm x 390 mm x 310 mm, and the weight is 49 kg. Optimal operating temperature ranges from 5 to 45 °C.

Technical Specifications

Line code
03

Design code
1

Bleeder
None

Interface
Analog

Feedback
Digital servo and resolver

Rated current
200 Amps

Cooling mode
Air, built-in blower

Ambient temperature range
5 to 45 degrees Celsius

Power voltage
400 to 480 Volts AC (three-phase, 50 to 60 Hertz)

Control voltage
200 Volts AC

Power
200 VA

Installation elevation
1000 meters

Max.ambient temperature with derating of nominal data
55 degrees Celsius

Storage and shipping temperature
-30 to 80 degrees Celsius

Protection rating
IP20

Weight of controller
49 kilograms

Weight of accessories kit
1.7 kilograms

Dimensions (H x W x D)
690 x 390 x 310 millimeters

Frequently Asked Questions

Does Bosch Rexroth Indramat DKR03.1-W200N-BA09-01-FW drive accept resolver feedback directly?

Yes, the drive natively supports resolver as well as digital servo feedback, ensuring precise position and speed control in dynamic industrial environments.

How does the Bosch Rexroth Indramat DKR03.1-W200N-BA09-01-FW drive manage excess thermal stress?

This drive employs an internal air-cooling system with a built-in blower, providing efficient heat dissipation without external cooling modules for stable operation.

What protective classification rating is assigned to Bosch Rexroth Indramat DKR03.1-W200N-BA09-01-FW drive?

The drive has an IP20 protection class, which offers limited ingress protection suitable for cabinet mounting but requires enclosed installation in industrial panels.

Where is Bosch Rexroth Indramat DKR03.1-W200N-BA09-01-FW drive most effectively installed?

It is installed inside closed electrical cabinets in industrial automation settings, where controlled ambient conditions ensure proper cooling and dust protection.

What is the required three-phase supply voltage for Bosch Rexroth Indramat DKR03.1-W200N-BA09-01-FW drive operation?

The drive requires a balanced three-phase supply of 400 to 480 Volts AC, operating reliably at both 50 Hz and 60 Hz grid standards.

Common Misspellings

DKR031W200NBA0901FW

DKR03 1 W200N BA09 01 FW

dkr03.1-w200n-ba09-01-fw

DKR3.1-W200N-BA09-01-FW

Internal Product Review

The Bosch Rexroth Indramat DKR03.1-W200N-BA09-01-FW drive by the DKR series is designed for precision control. It is marked with CE certification and has digital servo with resolver feedback. This drive is used in industrial automati and advanced servo applications requiring precise motion control and reliability.
