R911297078 (DKR03.1-W200N-BA24-01-FW)

Name: R911297078 (DKR03.1-W200N-BA24-01-FW)
Brand: Indramat Drives
SKU: DKR03.1-W200N-BA24-01-FW
Price: 945.00 USD
Availability: InStock

DKR Drive Controllers

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911297078 (DKR03.1-W200N-BA24-01-FW) is a Rexroth Indramat drive controller from the DKR03 series, designed for industrial applications. It employs internal cabinet air cooling with a built-in blower and supports modification for alternative cooling methods prior to installation. The unit features a rated current of 200 Amps, operates with a supply voltage of 400-480V AC, and provides analog command interface with digital servo and resolver feedback. Constructed without a brake chopper (rigid DC bus), it has a function numeric code of 24, version 01, and dimensions of 690 mm x 390 mm x 310 mm, with a weight of 108 lbs. Operation is specified for ambient temperatures from 4°C to 45°C and up to 1000 meters elevation.

Technical Specifications

Cooling Method
Internal Air with Built-in Blower

Mounting Setup
Must Prepare Threaded Holes in Panel

Weight
108 pounds

Dimensions
690mm x 390mm x 310mm (H x W x D)

Mounting
Vertical

Installation Altitude
Up to 1000 meters (No Derating)

Rated Current
200 Amps

Input Power
400 to 480 Volts AC, 3-Phase, 50 to 60 Hertz

Functional Numeric Code
24

Version of Functional Numeric Code
01

Item Availability
Global Shipping

Frequently Asked Questions

What is the cooling principle used in the Bosch Rexroth Indramat DKR03.1-W200N-BA24-01-FW drive?

The drive employs internal air cooling supported by a built-in blower, ensuring efficient heat dissipation and sustained performance even under extended industrial load operations.

Does the Bosch Rexroth Indramat DKR03.1-W200N-BA24-01-FW drive require derating at higher altitudes?

No derating is required up to 1000 meters installation altitude, ensuring stable operation in standard industrial environments without performance compromise.

What is the rated input electrical specification for the Bosch Rexroth Indramat DKR03.1-W200N-BA24-01-FW drive?

It accepts 400–480 Volts AC, three-phase, at 50 to 60 Hertz, providing compatibility with standard industrial mains power configurations.

How is rated current defined for the Bosch Rexroth Indramat DKR03.1-W200N-BA24-01-FW drive?

The rated current is 200 Amps, which ensures adequate handling of load currents in heavy-duty automation and machining applications.

What dimensional configuration is provided for the Bosch Rexroth Indramat DKR03.1-W200N-BA24-01-FW drive?

Its dimensions are 690 mm in height, 390 mm in width, and 310 mm in depth, optimized for industrial cabinet installations.

Common Misspellings

DKR031W200NBA2401FW

DKR03 1 W200N BA24 01 FW

dkr03.1-w200n-ba24-01-fw

DKR3.1-W200N-BA24-01-FW

Internal Product Review

The Bosch Rexroth Indramat DKR03.1-W200N-BA24-01-FW drive by DKR series is used to handle industrial requirements with precision. It uses global compatibility for operating between 400–480V AC voltage and has 50–60 Hz operational frequency span. This drive is applied in machining centers and heavy-duty processing units where vertical mounting and stable current flow are essential.
