R911306922 (DKR02.1-W200N-BE34-02-FW)

DKR Drive Controllers

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 19 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Rexroth Indramat MPN R911306922 (DKR02.1-W200N-BE34-02-FW) is a drive controller designed for precise motion control in industrial applications. It features a cooling system with a built-in blower that utilizes external air to regulate device temperature. The unit is configured for operation within an ambient temperature range of +5°C to +45°C and permits installation up to 1000 meters above sea level without derating. The enclosure holds an IP20 rating, necessitating installation within a protected switch cabinet. It is rated for a continuous current of 200 A and a power output up to 55 kW, drawing 200 VA from a 3-phase AC supply. The controller integrates a SERCOS interface for command communication, supports digital servo and resolver feedback, and is constructed with a rigid DC bus without a bleeder or brake chopper. Maximum motor feedback cable length is 75 meters. Suitable applications include NC machine tools and printing or paper-processing machines.

Technical Specifications

Configuration
Required before mounting

Mounting Direction
Allowable only

Clearance
Minimum 160mm at top and bottom

Cooling
Built-in blower unit (external air)

Operating Temperature
+5 to +45 degree Celsius

Maximum Altitude
1000 m/sea level (without derating)

Housing Protection
IP20

Power Source
3-phase AC

Rated Power Requirement
200 VA

Functional Reliability
High

Speed Range
Broad

Communication Interface
SERCOS

Motor Control
Digital servo and resolver feedback

Motor Feedback Cable Length
Maximum 75 meters

Motor Extras
Temperature control, holding brake

Maximum Power Output
55 kW

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the DKR02.1-W200N-BE34-02-FW.

Exchange

Want to sell your DKR02.1-W200N-BE34-02-FW?
