DKS01.1-W050A-RL01-01-FW
DKS Intelligent Digital Servo Drives
The Bosch Rexroth Indramat DKS01.1-W050A-RL01-01-FW digital servo drive from the DKS Series combines compact footprint with robust control to address demanding automation tasks. It operates on a 230V 3-Phase supply and delivers a continuous Rated Current of 50A to high-inertia loads. An integrated dynamic braking resistor provides rapid deceleration and stopping without external hardware. With a programmable error reaction system and built-in protection, this unit maximizes uptime and reduces system complexity.
Engineered as a Digital Servo Drive, the DKS01.1-W050A-RL01-01-FW employs passive Heat dissipation cooling method, eliminating the need for fans and lowering maintenance requirements. Noise emission remains at Standard levels under full load, making it suitable for noise-sensitive production environments. The drive features an Integral Holding Brake within its control and monitoring interface, ensuring reliable load retention when powered down. A fully integrated Power Shut-off Protection System guards against uncontrolled shutdowns, while the embedded Programmable Error Reaction to System Faults enables customizable fault management and simplifies commissioning.
Designed for seamless integration into modular machine architectures, this drive supports standardized mounting and wiring practices. Its proven reliability and compact design reduce cabinet space and heat load, while the programmable fault routines accelerate diagnostics and minimize downtime. Ideal for packaging machines, gantry systems, and high-speed assembly lines, the DKS01.1-W050A-RL01-01-FW drive boosts productivity and operational safety across diverse industrial applications.
Technical Specifications
Bleeder Continuous Power
0.35 kW
Bleeder Peak Power
9.4 kW
Continuous Current
25 A
Cooling Method
Heat dissipation
Dc Bus Voltage
300 V DC
Encoder Interface
Resolver
Line Frequency
50–60 Hz
Max Ambient (derated)
+55 °C
Max Elevation (no Derating)
1000 m
Noise Emission
Standard
Power Loss (max, Excl. Bleeder)
305 W
Power Requirement (max Load)
9.5 kVA
Product Type
Digital Servo Drive
Protection Class
IP10
Pwm Frequency
4 kHz
Rated Current
50A
Version
1
Frequently Asked Questions
Common Misspellings
Internal Product Review
The DKS01.1-W050A-RL01-01-FW is a robust digital servo drive from Bosch Rexroth Indramat, designed for demanding motion control applications. With a rated current of 50A and a DC bus voltage of 300 V DC, it supports high-performance tasks efficiently. The unit's heat dissipation cooling and standard noise emission provide reliable operation in industrial environments.
