R911268272 (DKS01.2-W100A-DA01-00)

DKS Intelligent Digital Servo Drives

Bosch Rexroth Indramat DKS AC Servo Drives DKS01.2-W100A-DA01-00 image

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Rexroth drive controller MPN R911268272 (DKS01.2-W100A-DA01-00) is designed for use with MDD series AC motors and operates with a rated current of 100 Amps and a continuous current of 50 Amps. It is configured for a DA01-00 layout and supports DSF type encoders. The unit requires a three-phase 230 V AC supply with a ±10% voltage tolerance, features an internal DC bus voltage of 300 V DC, and offers a maximum power output of 11 kVA. The bleeder circuit manages regenerative power between 0.5 and 18 kW, while the maximum device power loss, not accounting for bleeder losses, is 480 W. The controller measures 373 x 170 x 260 mm, weighs 11 kg, and is constructed to minimize ingress of solids and water, necessitating installation in a cool, dry location with proper grounding and regulated airflow. Heat dissipation is by standard methods.

Technical Specifications

Rated Drive Current
100 Amps

Noise Emission
Standard

Configuration Designation
DA01-00

Encoder Type
DSF

Peak Current
100 Amps

Continuous Current
50 Amps

Input Rating
3-Phase 230 Volts AC (±10 Tolerance)

Line Frequency Range
50-60 Hertz

Maximum Power Requirement
11 kVA

Internal DC Bus Voltage
300 Volts DC

Continuous Bleeder Power
0.5 Kilowatts

Peak Bleeder Power
18 Kilowatts

Maximum Power Loss (Excluding Bleeder Power Loss)
480 Watts

Storage Temperature
-30 to 85 Degrees Celsius

Transient Vibration Resistance
Yes

Dust and Moisture Resistance
Yes

Installation Area
Inside Control Cabinet

Maximum Relative Humidity
F (DIN 40 040)

Ambient Temperature Range
5-45 Degrees Celsius

Weight
11 Kilograms

Dimensions
373 x 270 x 260 Millimeters
